Network structures
6.2 VLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
228 Configuration Manual, 10/2015, C79000-G8976-C351-05
With this command, you change the agent VLAN ID. You can only use VLANs that have
already been configured.
Note
Changing the agent VLAN ID
If the configuration PC is connected
directly to the device via Ethernet and you change the
agent VLAN ID, the device is no longer reachable via Ethernet following the change.
● In "base bridge-mode", the mode for the device is set to dot1q-vlan
You are in the Global Configuration mode.
The command prompt is as follows:
cli(config)#
Call up the command with the following parameters:
mgmt vlan <vlan-id(1-4094)>
The parameter has the following meaning:
Number of the addressed VLAN
The Agent VLAN ID has been changed.
You reset the dot1q-vlan setting with the base bridge-mode command.
