Network structures
6.1 WLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
Configuration Manual, 10/2015, C79000-G8976-C351-05
197
wlan guard interval (access point)
Description
With this command, you specify the send pause that must be kept to between two
transferred OFDM symbols.
Note
This command is available only in access point mode.
● The IEEE 802.11n transmission standard is enabled.
You are in the Interface Configuration mode of the WLAN interface.
The command prompt is as follows:
cli (config-if-wlan-0-X)#
Call up the command with the following parameters:
wlan guard interval { GI400 | GI800 }
The parameters have the following meaning:
The send pause is 400 ns (default)
The function is enabled and the send pause set.
You display the setting with the show wlan advanced-11n <wlan 0/X> command.
