Layer 3 functions
9.1 NAT
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
Configuration Manual, 10/2015, C79000-G8976-C351-05
377
You show the NAT configuration and the translation list with the show nat command.
show nat (Client) (Page 371)
Note
This command is only available in the client mode.
With this command, you enable NAT for the Ethernet interface.
You are now in the NAT Configuration mode.
The command prompt is as follows:
cli(config-nat)#
● "Own" is set for "MAC Mode".
Call up the command with the following parameters:
nat interface <interface-type><interface-id>}
The parameters have the following meaning:
Type or speed of the interface
Enter a valid interface.
Module no. and port no. of the interface
For information on identifiers of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 25)".
NAT is activated for the Ethernet interface.
