Network structures
6.1 WLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
142 Configuration Manual, 10/2015, C79000-G8976-C351-05
show wlan overlap-ap-list (access point)
Description
This command shows all access points that are visible on the set or adjacent channels (at
2.4 GHz). If entries exist here, the maximum data throughput of the access point will be
restricted.
Note
This command is available only in access point mode.
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
Call up the command with the following parameters:
show wlan overlap-ap-list <wlan 0/X>
The parameter has the following meaning:
For information on identifiers of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 25)".
The access points are displayed.
