Network structures
6.2 VLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
Configuration Manual, 10/2015, C79000-G8976-C351-05
225
With this command, you create a VLAN on the device and change to the VLAN configuration
mode.
Note
The device supports up to 2 virtual networks.
In the provider backbone bridge mode, this command is used to create user, service and
backbone VLANs.
You are in the Global Configuration mode.
The command prompt is as follows:
cli(config)#
Call up the command with the following parameters:
vlan <vlan-id(1-4094)>
The parameter has the following meaning:
Number of the addressed VLAN
Do not enter any leading zeros with the number of the VLAN.
The VLAN is created.
You are now in the VLAN configuration mode.
The command prompt is as follows:
cli(config-vlan-$$$)#
You delete the VLAN with the no vlan command.
You can display information about the VLAN with the
show vlan command.
