Network structures
6.1 WLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
Configuration Manual, 10/2015, C79000-G8976-C351-05
169
wlan antenna type
Description
With this command, you specify which antenna type is connected to the relevant antenna
connector.
You are in the Interface Configuration mode of the WLAN interface.
The command prompt is as follows:
cli (config-if-wlan-0-X)#
Call up the command with the following parameters:
wlan antenna type {show
-types | <index(1)> <antenna
-index>} The parameters have the following meaning:
Shows a list of supported antennas
with the corresponding antenna index.
--
Antenna connector 1
Antenna index Enter the required antenna index.
You can obtain an overview of the an-
tenna indexes available on the
SCALANCE W700 device with the
wlan
antenna type show-types command.
The antenna type is specified.
