R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1005User Manual 1173.9163.02 ─ 62
Parameters:
<Boolean> ON - time domain representation active.
OFF - frequency domain representation active.
*RST: OFF
Example:
*RST; :CALC:TRAN:TIME:STAT?
Reset the instrument, activating a frequency sweep, and query
whether the default trace is displayed in the time domain. The
response is 0.
Manual operation: See "Time Domain" on page 349
CALCulate<Chn>:TRANsform:TIME:STIMulus
<Type>
Selects the type of stimulus to be simulated in the low pass transformation process.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Type> IMPulse | STEP
IMPulse - impulse response, in bandpass or lowpass mode.
STEP - step response, only in lowpass mode (a bandpass mode
setting CALCulate<Chn>:TRANsform:TIME[:TYPE] BPASs
is automatically changed to lowpass).
*RST: IMP
Example: See CALCulate<Chn>:TRANsform:TIME[:TYPE]
Manual operation: See "Type" on page 349
CALCulate<Chn>:TRANsform:TIME:STOP <StopTime>
Defines the stop time of the diagram in time domain.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<StopTime> Stop time of the diagram.
Range: -99.999999999998 s to +100 s.
Increment: 0.1 ns
*RST: +4E-009 s
Default unit: s
Example: See CALCulate<Chn>:TRANsform:TIME:STARt
Manual operation: See "Time Start / Time Stop / Time Center / Time Span"
on page 418
Note: If the x-axis is scaled in distance units (CALCulate<Chn>:TRANsform:TIME:
XAXis DISTance), then the stop value is entered in m; the range and default value
changes accordingly.
SCPI command reference
