R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
855User Manual 1173.9163.02 ─ 62
CALCulate:DATA:TRACe <TraceName>, <Format>, <Data>...
The query gets the trace data of an arbitrary (not necessarily the active) trace, refer-
enced by its trace name <TraceName>.
The "set direction" allows to import formatted or unformatted trace data to an existing
trace (data access point 3 or 2 in Chapter 4.1.5, "Data flow", on page 98).
Note
●
Unformatted trace data (SDATa) can only be imported to memory traces
●
Formatted trace data (FDATa) can only be imported to "live" traces if the related
channel is in single sweep mode (INITiate<Ch>:CONTinuous OFF).
Before the import, the target trace must be prepared according to the settings used
during export. Any request for new data from the hardware ("Restart Sweep" in sin-
gle sweep mode or switching to continuous sweep mode) discards imported data
and switches back the display to measured data.
Parameters:
<TraceName> String parameter containing the trace name
<Format> FDATa | SDATa | MDATa | NCData | UCData
Data format; see Table 7-2.
<Data> Trace data for FDATa | SDATa import either in ASCII or block
data format, depending on the current FORMat[:DATA] setting.
The column order must match the one used during export.
Example: See CALCulate<Chn>:DATA.
7.3.1.3 CALCulate:DTIMe...
Defines the properties and retrieves the results of the skew measurement provided
with the Extended time domain analysis option R&S ZNB/ZNBT-K20.
CALCulate<Chn>:DTIMe:DATA?..................................................................................... 855
CALCulate<Chn>:DTIMe:LIMit:FAIL?...............................................................................856
CALCulate<Chn>:DTIMe:LIMit:FAIL:BEEP....................................................................... 856
CALCulate<Chn>:DTIMe:LIMit:LIMit................................................................................ 857
CALCulate<Chn>:DTIMe:LIMit:STATe.............................................................................. 857
CALCulate<Chn>:DTIMe:POSition...................................................................................857
CALCulate<Chn>:DTIMe:STATe...................................................................................... 857
CALCulate<Chn>:DTIMe:TARGet....................................................................................858
CALCulate<Chn>:DTIMe:DATA? [<Data>]
Queries the results of the skew measurement
Suffix:
<Chn>
.
Channel number used to identify the active trace
SCPI command reference
