R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
887User Manual 1173.9163.02 ─ 62
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<TimeGate> RECT | HAMMing | HANNing | BOHMan | DCHebyshev
RECT - steepest edges (rectangle)
HANN - normal gate (Hann)
HAMMing - steep edges (Hamming)
BOHMan - minimum flatness (Bohman)
DCHebyshev - arbitrary gate shape (Dolph-Chebychev)
*RST: HANN
Example: See CALCulate<Chn>:FILTer[:GATE]:TIME:DCHebyshev
Manual operation: See "Shape" on page 354
7.3.1.6 CALCulate:FMODel...
The CALCulate:FMODel... commands are related to "fixture modeling" tools (see
Chapter 4.6.2.9, "Fixture modeling and deembedding", on page 217).
● CALCulate:FMODel:DEASsistant......................................................................... 887
● CALCulate:FMODel:DELT.....................................................................................893
● CALCulate:FMODel:EZD...................................................................................... 902
● CALCulate:FMODel:ISD....................................................................................... 908
● CALCulate:FMODel:SFD...................................................................................... 917
● CALCulate:FMODel... (other)................................................................................921
CALCulate:FMODel:DEASsistant...
These commands implement the functionality of the Deembed Assistant tab and the
related Deembedding Assistant dock widget panel.
The deembedding assistant functionality requires at least one of the fixture deembed-
ding software options:
●
R&S ZNB/ZNBT-K220 (see Chapter 4.7.9, "In-situ de-embedding", on page 251)
●
R&S ZNB/ZNBT-K230 (see Chapter 4.7.10, "Smart fixture de-embedding",
on page 252)
●
R&S ZNB/ZNBT-K210 (see Chapter 4.7.8, "Eazy de-embedding based on IEEE
370", on page 250)
If options are of these available, the CALCulate:FMODel:DEASsistant commands
cannot be used.
CALCulate:FMODel:DEASsistant:COUPon:LEFT:CLEar
CALCulate:FMODel:DEASsistant:COUPon:RIGHt:CLEar
Clears the test coupon data available for the lead-in/lead-out.
Usage:
Event
SCPI command reference
