Command reference
R&S
®
ZNB/ZNBT
888User Manual 1173.9163.02 ─ 62
Options: R&S ZNB/ZNBT-K220 | R&S ZNB/ZNBT-K230 | R&S ZNB/
ZNBT-K210
Manual operation: See "Coupon A / Coupon B section" on page 658
CALCulate:FMODel:DEASsistant:COUPon:LEFT:FILE <CouponType>, <Path>
CALCulate:FMODel:DEASsistant:COUPon:RIGHt:FILE <CouponType>, <Path>
Loads the properties of a test coupon for the lead-in/lead-out of the DUT.
Parameters:
<CouponType> SYMMetric2x | OPEN1x | SHORt1x
<Path> Path to the Touchstone file, either absolute or relative to the
selected working directory (CALCulate:FMODel:DIRectory).
For
CALCulate:FMODel:DEASsistant:COUPon:
<LEFT|RIGHt>:TYPE OPSHort1x, you have to load a file for
OPEN1x and SHORt1x (or measure it). Otherwise only for the
selected coupon type.
Options: R&S ZNB/ZNBT-K220 | R&S ZNB/ZNBT-K230 | R&S ZNB/
ZNBT-K210
Manual operation: See "Deembedding Files..." on page 653
CALCulate:FMODel:DEASsistant:COUPon:LEFT:MEASure <CouponType>
CALCulate:FMODel:DEASsistant:COUPon:RIGHt:MEASure <CouponType>
Measures the test coupon.
Before measuring, select the test coupon type using CALCulate:FMODel:DEAS
sistant:COUPon:<LEFT|RIGHt>:TYPE and the ports using CALCulate:FMO
Del:DEASsistant:COUPon:<LEFT|RIGHt>:PORT.
Setting parameters:
<CouponType> SYMMetric2x | OPEN1x | SHORt1x
Test coupon type to be measured
For
CALCulate:FMODel:DEASsistant:COUPon:
<LEFT|RIGHt>:TYPE OPSHort1x, you have to measure
OPEN1x and SHORt1x (or load it from file). Otherwise measure
only the selected coupon type.
Usage: Setting only
Options: R&S ZNB/ZNBT-K220 | R&S ZNB/ZNBT-K230 | R&S ZNB/
ZNBT-K210
Manual operation: See "Coupon A / Coupon B section" on page 658
