5.12.4.3 Define Intermodulation Distortion Measurement dialog
The dialog configures the intermodulation measurement (except for power and fre-
quency settings). The "OK" button is available when a valid configuration has been
defined.
Access: Channel – [Channel Config] > "Intermod" > "Define Intermod..."
Independent sources for the lower and upper tone requires a R&S ZNB/ZNBT with two
internal sources (see Chapter 4.7.14, "Internal second source", on page 255). Alterna-
tively an external generator can be used, see Chapter 4.7.4.3, "Intermodulation mea-
surements", on page 241.
