R&S ZNB Series User Manual

GUI reference
R&S
®
ZNB/ZNBT
394User Manual 1173.9163.02 ─ 62
"Coupling Type" Label
"All" "Coupled Markers"
"Channel" "Coupled Markers in <name of active channel>"
"Diagram" "Coupled Markers in <name of active diagram>"
Coupling also works if Tracking is enabled for Marker <m> in one trace. The Marker
<m> of the other traces then follow the movements of the tracked marker. The same
holds true for the reference marker.
Remote command:
CALCulate:MARKer:COUPled[:STATe]
5.7.2 Marker Props tab
Modifies the properties of a marker created previously (see Chapter 5.7.1, "Markers
tab", on page 391). The functions (except "Export Markers...") are unavailable if the
active trace contains no markers.
Marker Name
Assigns a (new) name to the active marker. Marker names can contain letters, num-
bers, blanks and special characters.
Remote command:
CALCulate<Chn>:MARKer<Mk>:NAME
CALCulate<Chn>:MARKer<Mk>:REFerence:NAME
Marker Format
Defines the formatting of the active marker in the movable marker info field.
For background information on marker formats, see "Marker format" on page 107.
Marker softtool
