Remote control
R&S
®
ZNB/ZNBT
833User Manual 1173.9163.02 ─ 62
STATus:QUEStionable:LIMit<1|2>[:EVENt]?
STATus:QUEStionable:LIMit1 is also the summary register of the lower level
STATus:QUEStionable:LIMit2 register.
The bits in the STATus:QUEStionable:LIMit1 register are defined as follows:
Bit No. Meaning
0 LIMit2 register summary
This bit is set if a bit is set in the STATus:QUEStionable:LIMit2 register and the associated
ENABle bit is set to 1.
1 Failed limit check for trace no. 1
This bit is set if any point on trace no. 1 fails the limit check.
... ...
14 Failed limit check for trace no. 14
This bit is set if any point on trace no. 14 fails the limit check.
The bits in the STATus:QUEStionable:LIMit2 register are defined as follows:
Bit No. Meaning
0 Not used
1 Failed limit check for trace no. 15
This bit is set if any point on trace no. 15 fails the limit check.
2 Failed limit check for trace no. 16
This bit is set if any point on trace no. 16 fails the limit check.
Numbering of traces
The traces numbers 1 to 16 are assigned as follows:
●
Traces assigned to channels with smaller channel numbers have smaller trace
numbers.
●
Within a channel, the order of traces reflects their creation time: The oldest trace
has the smallest, the newest trace has the largest trace number. This is equivalent
to the order of traces in the response string of the
CALCulate<Ch>:PARameter:CATalog? query.
●
The number of traces monitored cannot exceed 16. If a setup contains more
traces, the newest traces are not monitored.
STATus:QUEStionable:INTegrity...
The STATus:QUEStionable:INTegrity register monitors hardware failures of the
analyzer. It can be queried using the commands
STATus:QUEStionable:INTegrity:CONDition? or
STATus:QUEStionable:INTegrity[:EVENt]?
STATus:QUEStionable:INTegrity is also the summary register of the lower level
STATus:QUEStionable:INTegrity:HARDware register.
Status reporting system
