HiSLIP protocol
The HiSLIP (High Speed LAN Instrument Protocol) is a protocol for TCP-based instru-
ments specified by the IVI foundation. Compared to its predecessor VXI-11, it provides
speed and other improvements. HiSLIP is encapsulated in VISA; the resource string
reads TCPIP::<R&S ZNB/ZNBT IP address>::hislip0.
The RS Visa library supports HiSLIP. If the connection fails, access the Windows con-
trol panel of the controlled instrument and open port 4880 for incoming connections.
6.1.1 Remote control via USB
The instrument can be remote-controlled via USB. The VISA resource string for con-
trolling a device via USB has to be specified in the format
USB[board]::<Manufacturer ID>::<Device ID>::<Serial Number>::
INSTR.
The <Manufacturer ID> of Rohde & Schwarz is 0x0AAD, the <Device ID> is
model-specific.
Table 6-1: R&S ZNB/ZNBT Device IDs
1st generation (1311.6010Kxx) 2nd generation (1334.3330Kxx)
2-port R&S ZNB4
0x019C 0x01E4
4-port R&S ZNB4
0x019D 0x01E5
2-port R&S ZNB8
0x019E 0x01E6
4-port R&S ZNB8
0x019F 0x01E7
2-port R&S ZNB20
0x01A0 0x01E8
4-port R&S ZNB20
0x01A1 0x01E9
2-port R&S ZNB26 -
0x0297
4-port R&S ZNB26 -
0x0298
2-port R&S ZNB40 var. 72
0x01A2
-
2-port R&S ZNB40 var. 82
0x01BF
-
2-port R&S ZNB40 var. 83
0x0263
-
4-port R&S ZNB40 var. 84
0x01C0
-
2-port R&S ZNB43 2.92 mm -
0x025B
4-port R&S ZNB43 2.92 mm -
0x025C
2-port R&S ZNB43 2.4 mm -
0x0268
4-port R&S ZNB43 2.4 mm -
0x0269
R&S ZNBT8
0x01BE
-
R&S ZNBT20
0x01A7
-
