Command reference
R&S
®
ZNB/ZNBT
994User Manual 1173.9163.02 ─ 62
CALCulate<Chn>:STATistics[:STATe]:AREA <HorizontalPos>, <VerticalPos>
Moves the statistics info field for the active trace <Chn> to one of nine predefined posi-
tions in the active diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<HorizontalPos> LEFT | MID | RIGHt
Horizontal position
<VerticalPos> TOP | MID | BOTTom
Vertical position
Example: See CALCulate<Chn>:STATistics[:STATe]
Manual operation: See "Min/Max/Peak-Peak, Mean/Std Dev/RMS" on page 355
7.3.1.13 CALCulate:TRANsform...
The CALCulate:TRANsform... commands convert measured data from one repre-
sentation to another.
● CALCulate:TRANsform:DTFault........................................................................... 994
● CALCulate:TRANsform:TIME............................................................................. 1000
● CALCulate:TRANsform:VNETworks................................................................... 1007
● CALCulate:TRANsform... (other)........................................................................ 1056
CALCulate:TRANsform:DTFault...
The CALCulate:TRANsform:DTFault... commands set up and control a distance
to fault measurement (with option R&S ZNB/ZNBT-K3).
CALCulate<Chn>:TRANsform:DTFault:CENTer................................................................ 994
CALCulate<Chn>:TRANsform:DTFault:SPAN................................................................... 994
CALCulate<Chn>:TRANsform:DTFault:DEFine.................................................................995
CALCulate<Chn>:TRANsform:DTFault:DELete.................................................................996
CALCulate<Chn>:TRANsform:DTFault:PEAK:COUNt?......................................................996
CALCulate<Chn>:TRANsform:DTFault:PEAK:DATA<FaultNo>...........................................997
CALCulate<Chn>:TRANsform:DTFault:PEAK:STATe......................................................... 997
CALCulate<Chn>:TRANsform:DTFault:PEAK:THReshold.................................................. 997
CALCulate<Chn>:TRANsform:DTFault:POINts................................................................. 998
CALCulate<Chn>:TRANsform:DTFault:SELect................................................................. 999
CALCulate<Chn>:TRANsform:DTFault:STARt.................................................................. 999
CALCulate<Chn>:TRANsform:DTFault:STOP...................................................................999
CALCulate<Chn>:TRANsform:DTFault:STATe.................................................................. 999
CALCulate<Chn>:TRANsform:DTFault:CENTer <Center>
CALCulate<Chn>:TRANsform:DTFault:SPAN <Span>
Defines the distance window of the Distance to Fault measurement using its center
and span.
