R&S ZNB Series User Manual

GUI reference
R&S
®
ZNB/ZNBT
284User Manual 1173.9163.02 ─ 62
(Virtual) Hardkey Keyboard Shortcut Related Softtool Action
System – [File Print]
2nd generation
R&S ZNB models only
(order nos.
1334.3330.xx)
Ctrl + O File softtool default
System – [File]
other R&S ZNB and
R&S ZNBT
Ctrl + O File softtool default
System – [Print]
2nd generation
R&S ZNB models only
(order nos.
1334.3330.xx)
Ctrl + P Chapter 5.15, "DUT
Softtool", on page 681
default
System – [Print]
other R&S ZNB and
R&S ZNBT
Ctrl + P "File" softtool opens the Print tab
System – [Applic] Alt + Shift + N Applic softtool default
System – [Display] Alt + Shift + S Display softtool default
System – [Setup] Alt + Shift + T Setup softtool default
System – [Windows®] Windows key none n.a.
System – [Help] F1 none n.a.
System – [Preset] Alt + Shift + U none n.a.
System – [Undo] Alt + Shift + V none n.a.
System – [Redo] Alt + Shift + I none n.a.
5.2 Meas softtool
The "Meas" softtool allows you to select the quantities to be measured and displayed.
Access: Trace – [Meas]
Background information
For a detailed description of all measurement results of the R&S ZNB/ZNBT, refer to
Chapter 4.3, "Measurement results", on page 125.
Efficient trace handling
To select a result and display it as a trace, you can simply drag and drop the corre-
sponding button into a diagram area. See also Chapter 3.3.5, "Handling diagrams,
traces, and markers", on page 66.
Meas softtool
