Characterization Data

Displays all characterizations which are stored on the active cal unit. The "Factory"

characterization is available for all calibration units; it ensures an accurate calibration

for all standard applications. Characterizations stored on an SD card (inserted at the

cal unit) are prefixed with "SD:".

Tip: Characterizations stored on an SD card (inserted at the cal unit) are prefixed with

"SD:".

The properties of the selected characterization are shown below the list. "Delete" dele-

tes the selected characterization file; "Start Characterization..." opens the Characteri-

zation wizard to create a characterization.

Remote command:

SYSTem:COMMunicate:RDEVice:AKAL:CKIT:CATalog?

SYSTem:COMMunicate:RDEVice:AKAL:CKIT:STANdard:CATalog?

SYSTem:COMMunicate:RDEVice:AKAL:SDATa?

Characterization wizard

The "Characterization" wizard guides you through the automatic characterization of a

calibration unit.

Access: Characterization wizard > "Start Characterization..."

The guided characterization consists of the following steps:

1. "Characterization": Select the characterized ports and cal unit standards to ini-

tiate the characterization sweeps.

2. "Save Characterization Data": Save the characterization data to the calibration

unit.

Step 1: Characterization

Selects the calibration type and the characterized cal unit ports and initiates the neces-

sary characterization sweeps.

Characterization procedure

To acquire accurate characterization data, the test setup must be properly calibrated

before you start the characterization wizard. Use the calibration type that you wish to

perform with your new cal unit characterization; see Chapter 4.5.5.3, "Characterization

of calibration units", on page 185.

Cal softtool

R&S ZNB Series User Manual
