R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1292User Manual 1173.9163.02 ─ 62
Example:
SENSe1:PAE:TYPE VOLTage
Select a measurement type with constant voltage source.
SENSe1:PAE:PARameters:U 5V; R 50Ohm
Define the parameters for the PAE measurement.
SENSe1:PAE:DCINput:MAIN DC1; :DC1:RANGe 20
Define the DC connector and power range
Alternative measurement type: constant current source.
SENSe1:PAE:TYPE CURRent
SENSe1:PAE:PARameters:I 100mA
SENSe1:PAE:DCINput:MAIN DC1; :DC1:RANGe 20
Alternative measurement type: voltange and current.
SENSe1:PAE:TYPE VCURrent
SENSe1:PAE:PARameters:R 50Ohm
SENSe1:PAE:DCINput:MAIN DC1; :DC1:RANGe 3
SENSe1:PAE:DCINput:SECondary DC2; :DC2:RANGe 20
For all measurement types:
CALCulate1:PARameter:SDEFine 'Trc1', 'PAE21'
DISPlay:WINDow1:TRACe:FEED 'Trc1'
Select a PAE measurement with port 1 as a source port, port 2
as a receive port.
Manual operation:
See "Measurement Type" on page 316
7.3.14.13 [SENSe:]POWer...
The [SENSe:]POWer... commands configure the optional receiver step attenuators
(see Chapter 4.7.23, "Receiver step attenuators", on page 261) and the AGC of the
R&S ZNB/ZNBT.
See also [SENSe<Ch>:]SEGMent<Seg>:POWer:GAINcontrol on page 1310.
[SENSe<Ch>:]POWer:AGCMode:ACQuire..................................................................... 1292
[SENSe<Ch>:]POWer:AGCMode<PhyPt>:MEASure....................................................... 1293
[SENSe<Ch>:]POWer:IFGain<PhyPt>:MEASure.............................................................1293
[SENSe<Ch>:]POWer:AGCMode:SAVE......................................................................... 1294
[SENSe<Ch>:]POWer:ATTenuation................................................................................1294
[SENSe<Ch>:]POWer:GAINcontrol................................................................................1295
[SENSe<Ch>:]POWer:GAINcontrol:ALL......................................................................... 1295
[SENSe<Ch>:]POWer:GAINcontrol:GLOBal................................................................... 1296
[SENSe<Ch>:]POWer:LOSuppress[:STATe]....................................................................1297
[SENSe<Ch>:]POWer:AGCMode:ACQuire
Starts an AGC learn sweep.
Suffix:
<Ch>
.
Channel number
SCPI command reference
