R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1289User Manual 1173.9163.02 ─ 62
Example:
*RST; :CALC:PAR:DEL 'TRC1'
Reset the analyzer and delete the (default) trace for channel no.
1.
SOUR:LPOR1 1,2
Combine the physical ports no. 1 and 2 to define the balanced
(logical) port no. 1.
LPOR1:ZDIF 27, 2
Specify a complex differential mode reference impedance of
27Ω + j * 2Ω for the defined port.
Manual operation: See "Single Ended Mode / Common Mode / Differential Mode"
on page 293
[SENSe<Ch>:]LPORt<LogPt>:ZDEFault[:STATe]
<arg0>
Allows to toggle between default and renormalized reference impedance(s) for logical
port <LogPt>.
Suffix:
<Ch>
.
Channel number
<LogPt> Logical port number
Parameters:
<arg0> ON (1): Use default impedance(s)
OFF (0): Use the redefined impedances defined via
[SENSe<Ch>:]PORT<PhyPt>:ZREFerence for single-ended
or via [SENSe<Ch>:]LPORt<LogPt>:ZCOMmon and
[SENSe<Ch>:]LPORt<LogPt>:ZDIFferent for balanced
logical ports
Manual operation: See "Use Default" on page 293
7.3.14.12 [SENSe:]PAE...
The [SENSe:]PAE... commands configure the measurement of the Power Added
Efficiency of an active 2-port device.
[SENSe<Ch>:]PAE:DCINput:MAIN................................................................................ 1289
[SENSe<Ch>:]PAE:DCINput:SECondary........................................................................ 1290
[SENSe<Ch>:]PAE:PARameters:I..................................................................................1290
[SENSe<Ch>:]PAE:PARameters:R.................................................................................1290
[SENSe<Ch>:]PAE:PARameters:U.................................................................................1291
[SENSe<Ch>:]PAE:TYPE............................................................................................. 1291
[SENSe<Ch>:]PAE:DCINput:MAIN <Input>
Selects the first (main) DC INPUT connector for the PAE measurement (used for all
measurement types; see example).
Suffix:
<Ch>
.
Channel number
SCPI command reference
