R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
917User Manual 1173.9163.02 ─ 62
CALCulate:FMODel:SFD...
Commands for PacketMicro's Smart Fixture De-embedding (SFD), see https://
www.packetmicro.com/Products/sfd-tool.html
CALCulate:FMODel:SFD:AUTO...................................................................................... 917
CALCulate:FMODel:SFD:COUPon:MEASure....................................................................917
CALCulate:FMODel:SFD:COUPon:MEASure:FILename.................................................... 918
CALCulate:FMODel:SFD:COUPon:MEASure:FILename:CLEar.......................................... 918
CALCulate:FMODel:SFD<Ph_pt>:COUPon[:STATe].......................................................... 918
CALCulate:FMODel:SFD:COUPon:TYPE......................................................................... 918
CALCulate:FMODel:SFD:DIFFcfg....................................................................................918
CALCulate:FMODel:SFD:DUT:MEASure.......................................................................... 919
CALCulate:FMODel:SFD:DUT:MEASure:FILename...........................................................919
CALCulate:FMODel:SFD:DUT:MEASure:FILename:CLEar.................................................919
CALCulate:FMODel:SFD<Ph_pt>:DUT[:STATe].................................................................919
CALCulate:FMODel:SFD:IMPedance...............................................................................920
CALCulate:FMODel:SFD:PRESet....................................................................................920
CALCulate:FMODel:SFD:RUN:RUN................................................................................ 920
CALCulate:FMODel:SFD<Ph_pt>:RUN[:STATe]................................................................ 920
CALCulate:FMODel:SFD:TOTaldiffcfg.............................................................................. 921
CALCulate:FMODel:SFD:AUTO <Boolean>
Enables/disables the impedance correction of the SFD tool.
This is a global setting.
Duplicate of CALCulate:FMODel:SFD:IMPedance, kept for backward compatibility.
Parameters:
<Boolean> ON (1)
Impedance correction enabled
OFF (0)
Impedance correction disabled
Manual operation: See "Use Impedance Correction" on page 629
CALCulate:FMODel:SFD:COUPon:MEASure
For a fixture modeling with the SFD tool, this command starts the measurement of the
coupon at the active ports (see CALCulate:FMODel:SFD<Ph_pt>:COUPon[:
STATe]).
The coupon type can be selected using CALCulate:FMODel:SFD:COUPon:TYPE.
Usage:
Event
Manual operation: See "Measure / Measure Open / Measure Short" on page 630
SCPI command reference
