GUI reference
R&S
®
ZNB/ZNBT
391User Manual 1173.9163.02 ─ 62
Remote command:
CALCulate<Chn>:DLINe:STATe
Response Value
Defines/shows the response value of the horizontal line.
Tip: Use the R&S ZNB/ZNBT's drag and drop functionality to move the horizontal line
to a particular position. The response value appears in the numeric entry field.
Remote command:
CALCulate<Chn>:DLINe
5.7 Marker softtool
The "Marker" softtool allows you to position markers on a trace and to define their
properties. Markers are also convenient tools for searching special points on traces
and for scaling diagrams.
Access: Trace – [Marker]
Background information
Refer to the following sections:
●
Chapter 4.2.1.3, "Markers", on page 105
●
Chapter 3.3.7.6, "Set by marker", on page 76
5.7.1 Markers tab
Creates markers and configures their properties. Markers are available for all trace for-
mats.
A first marker labeled "M1" is automatically created when the [Marker] hardkey is
pressed. The "Mkr 1" ... "Mkr 10" and "Ref Mkr" softkeys enable the corresponding
markers.
"Add Marker" adds a new marker.
Related information
Refer to the following sections:
●
Chapter 4.2.1.3, "Markers", on page 105
●
Chapter 3.3.5, "Handling diagrams, traces, and markers", on page 66
Marker softtool
