GUI reference
R&S
®
ZNB/ZNBT
767
User Manual 1
173.9163.02 ─ 62
Create R&S Support Information
Saves the current selftest results to a zipped report file you can send to R&S Support
for fault diagnosis; see
Chapter 9.3, "Collecting information for technical support"
,
on page 1532.
Remote command:
DIAGnostic:DEVice:STATe
SYSTem:DFPRint?
Setup tab
Displays the channel and trace settings of the active recall set and the main character-
istics of the instrument, including its IP address.
Setup softtool
766
768
