R&S ZNB Series User Manual

GUI reference
R&S
®
ZNB/ZNBT
743User Manual 1173.9163.02 ─ 62
The info table is a possible container for info fields and can be placed to the bottom, to
the left, or to the right of the screen. See also Chapter 5.7.8, "Info Field tab",
on page 412.
Remote command:
No command; display configuration only.
Info Window
Shows/hides the Info Window
Remote command:
DISPlay:IWINdow[:STATe]
Font Size
Scales the fonts in the diagrams. The scaling affects the trace and channel lists, and
the info fields.
Remote command:
DISPlay:RFSize
5.17.3.2 Define User Color Scheme dialog
The "Define User Color Scheme" dialog allows you to configure user-defined diagram
color schemes for display and print. User-defined color schemes can be saved to a file
for later re-use.
Access:
●
System – [Display] > "Config" > "Define User Color..."
●
Printer Setup dialog > "Print" tab > "Define Print Color..."
Related settings
Refer to "Color Scheme" on page 741.
Display softtool
