R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1106User Manual 1173.9163.02 ─ 62
<TraceStyle> SOLid | DASHed | DOTTed | DDOTted | DDDotted
Optional trace style, only for traces (<DispEl> > 12): One of the
string parameters SOLid | DASHed | DOTTed | DDOTted
| DDDotted.
<TraceWidth> Optional trace width, only for traces (<DispEl> > 12).
Range: 1 to 20
Example:
*RST; :DISP:CMAP:TRAC:RGB 'Trc1', 1, 0, 0
Color the default trace 'Trc1' red.
See also DISPlay:CMAP<DispEl>:RGB
Manual operation: See "Properties" on page 744
DISPlay:IWINdow:BFILter[:STATe] <TraceName>, <BandfilterItem>, <Boolean>
Defines the bandfilter search results to be displayed in the Info Window.
Parameters:
<Boolean> 0 – Result <BandfilterItem> of trace <TraceName> is displayed
1 – Result <BandfilterItem> of trace <TraceName> is hidden
Setting parameters:
<TraceName> Name of the related trace.
<BandfilterItem> CENTer | BANDwidth | UPPer | LOWer | LOSS | QFACtor |
QFA3 | HEADer
Bandfilter search result (see Display elements of a diagram)
Manual operation: See "Content Selection" on page 747
DISPlay:IWINdow:MARKer<Mk>[:STATe] <TraceName>, <Boolean>
Defines the markers to be displayed in the Info Window.
Suffix:
<Mk>
.
Marker number.
Parameters:
<Boolean> 0 – Marker <Mk> of trace <TraceName> is displayed
1 – Marker <Mk> of trace <TraceName> is hidden
Setting parameters:
<TraceName> Name of the related trace.
Manual operation: See "Content Selection" on page 747
DISPlay:IWINdow[:STATe] <Boolean>
Shows/hides the Info Window
