R&S ZNB Series User Manual

GUI reference
R&S
®
ZNB/ZNBT
547User Manual 1173.9163.02 ─ 62
5.12 Channel Config softtool
The "Channel Config" functions select, create and delete channels, configure the
source and receive ports of the R&S ZNB/ZNBT, and optimize the measurement proc-
ess.
Access: Channel – [Channel Config] hardkey
5.12.1 Channels tab
Allows you to create and delete channels, to modify the channel state, and to select a
channel as the active channel.
You can monitor the channel activity using the OUTPut<Ch>:UPORt[:VALue] com-
mand and the output signals at pins 8 to 11 of the User Port connector.
Background information
Refer to Chapter 4.1.3.3, "Active and inactive traces and channels", on page 90.
5.12.1.1 Controls on the Channels tab
The buttons in the "Channels" tab open the following dialogs:
●
"Channel Manager...": see Chapter 5.12.1.2, "Channel Manager dialog",
on page 550
●
"RFFE...": see Chapter 5.12.1.3, "RFFE Config dialog for R&S ZN-B15/-Z15 Var.
03", on page 551
Channel Config softtool
