R&S ZNB Series User Manual

GUI reference
R&S
®
ZNB/ZNBT
676User Manual 1173.9163.02 ─ 62
If selected in the "Print other information" group, the content of the "Info Table" (see
"Info Table: Show / Position" on page 742) and/or "Setup Info" (see "Setup tab"
on page 767) is printed on additional pages.
5.14.4.2 Printer tab
The "Printer" settings select one of the installed printers and specify printer options.
Printers can be installed using the Windows
®
"Devices and Printers" functionality; see
also Chapter 3.1.11.4, "Connecting a printer", on page 33.
Print Options
Allows you to select and/or define the color scheme for printing.
The "Define Print Color..." button opens the Define User Color Scheme dialog which
allows you to create or modify your own print color scheme.
The R&S ZNB/ZNBT now uses different "User Defined" color schemes for display and
printing.
Remote command:
HCOPy:PAGE:COLor
5.14.4.3 Page Setup tab
The "Page Setup" settings are visualized in the preview page in the lower part of the
dialog.
Tip: The printer settings are not affected by a preset of the R&S ZNB/ZNBT. Use the
"Remote" tab in the System Config dialog to restore default settings.
5.14.5 Trace Data tab
See Chapter 5.5.11, "Trace Data tab", on page 365.
