5.13.11 Deembed Assistant tab
The "Deembed Assistant" softtool tab and the related Deembedding Assistant dock
widget panel simplify common fixture deembedding scenarios.
The deembedding assistant functionality requires at least one of the fixture deembed-
ding software options:
●
R&S ZNB/ZNBT-K220 (see Chapter 4.7.9, "In-situ de-embedding", on page 251)
●
R&S ZNB/ZNBT-K230 (see Chapter 4.7.10, "Smart fixture de-embedding",
on page 252)
●
R&S ZNB/ZNBT-K210 (see Chapter 4.7.8, "Eazy de-embedding based on IEEE
370", on page 250)
If none of these options are available, the "Deembed Assistant" tab is hidden.
Background information
Refer to Chapter 4.6.2.9, "Fixture modeling and deembedding", on page 217.
5.13.11.1 Controls on the Deembed Assistant tab
Overview
This button is available on all "Offset Embed" softtool tabs. It opens the Overview panel
in the Offset Embed dock widget.
Offset Embed softtool
