Guided amplifier setup
Define DUT
The "Define DUT" step allows you to specify basic properties of an amplifier or load
them from the DUT Manager.
Similar to the Amplifier Configuration dialog of the DUT Manager.
Load from DUT Manager
Use "Load from DUT Manager" to load a previously configured mixer from the DUT
manager.
This will open a dialog that allows you to select the DUT to be loaded:
Save to DUT Manager
Use "Save to DUT Manager" to persist new/modified mixer settings to the DUT man-
ager when you proceed to the next step of the "DUT Centric Wizard". If a DUT with the
same name exists, you are asked whether you want to overwrite the existing DUT con-
figuration, or to create a DUT with a different name.
