Deembed Two-Port (All Channels)
Reads and modifies the state of the built-in S-parameter correction that is available on
certain R&S®NRP-Z power sensors. See Application Note 1GP70 "Using S-Parame-
ters with R&S®NRP-Z Power Sensors" for background information. This Application
Note is available on the Rohde & Schwarz internet at http://www.rohde-schwarz.com/
appnotes/1GP70.
Remote command:
SYSTem:COMMunicate:RDEVice:PMETer<Pmtr>:SPCorrection[:STATe]
5.18.4.4 External Generators dialog
The "External Generators" dialog configures external generators so that they can be
used for measurements and power calibrations.
Access: System – [Setup] > "External Devices" > "Generators..."
Background information
Refer to section Chapter 4.7.28, "External generators", on page 267.
Setup softtool
