GUI reference
R&S
®
ZNB/ZNBT
755User Manual 1173.9163.02 ─ 62
Search Path for additional Cal Kits and Connector Types
Contains the name and path of a special directory for cal kit files (*.calkit). All cal
kit files in the special directory are loaded automatically as predefined kits (i.e. read-
only kits which cannot be modified) every time the VNA application is started. It is pos-
sible to select the default cal kit directory
C:\Users\Public\Documents\Rohde-Schwarz\Vna\Calibration\Kits or
any other directory. "None" means that no additional cal kit files are loaded on start-up.
Use the special directory to make sure that you do not have to import kits manually,
even after terminating the VNA application improperly. In this case, previously imported
cal kit files are not stored in the recall set file.
Remote command:
MMEMory:LOAD:CKIT:UDIRectory
User Interface tab
Provides general user interface configurations.
Transparent Info Fields
This checkbox enables or disables transparent info fields for markers and trace statis-
tics.
Transparent info fields do not hide an underlying trace.
Remote command:
n.a.
Setup softtool
