Characterization

See "Characterization" on page 451.

Temperature Compensation

Available for inline calibration systems (ICS) only. Applies to all inline calibration units

(ICUs) that are connected to the ICS and that are used with factory characterization

data.

If checked, the R&S ZNB/ZNBT firmware adjusts the factory characterization data

according to the ICU temperatures.

Remote command:

[SENSe<Ch>:]CORRection:COLLect:AUTO:TEMPcomp

Calibration Type

Selects the calibration type for the selected physical ports. For an overview, refer to

Chapter 4.5.7.2, "Calibration types", on page 200. The calibration types PUOSM and

PTOSM are compatible with all port combinations.

Remote command:

[SENSe<Ch>:]CORRection:COLLect:AUTO:TYPE

[SENSe<Ch>:]CORRection:COLLect:AUTO:PORTs:TYPE

[SENSe<Ch>:]CORRection:COLLect:AUTO:CONFigure

Power Meter

Shows a list of all power meters that have been properly configured and are available

for the scalar source power calibration of a single source port. The last configured

power meter is selected by default. See "Configured Devices" on page 782.

Remote command:

[SENSe:]CORRection:COLLect:PMETer:ID

Power Port

Selects the port for the scalar source power calibration.

Select All/Deselect All

Selects/deselects all ports.

These buttons are only shown if more than 4 ports are available.

Step 2: Connections

Defines the port assignments between the R&S ZNB/ZNBT and the calibration unit.

Related information

Refer to Chapter 4.5.5.6, "Multiple port assignments", on page 191 for details on multi-

ple port assignments.

The layout of the main panel depends on the number of test ports available.

Cal softtool
