R&S ZNB Series User Manual

GUI reference
R&S
®
ZNB/ZNBT
468User Manual 1173.9163.02 ─ 62
Remote command:
[SENSe<Ch>:]CORRection:COLLect:CONNection:PORTs
[SENSe<Ch>:]CORRection:COLLect:CONNection:GENDers
Import Cal Kit...
Opens the "Import Calibration Kit" dialog that allows you to import a cal kit file. For
background information, see Chapter 4.5.2.4, "Cal kit Files", on page 179.
Remote command:
MMEMory:LOAD:CKIT
Back
Go back to Step 1: Ports and Type.
Start
Start Step 3: Calibration.
Step 3: Calibration
Allows you to acquire error correction data for every required port (pair) and calibration
standard, where "required" depends on the selected ports and calibration type. On
"Apply", the R&S ZNB/ZNBT calculates the system error correction (error terms) from
the measurement data of the standards and applies the result to the active channel.
The "Reduced Through" logic helps to keep the number of transmission measurements
as small as possible (see Chapter 4.5.1.11, "Full n-Port calibration with reduced num-
ber of Through connections", on page 173).
Cal softtool
