R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1231User Manual 1173.9163.02 ─ 62
[SENSe<Ch>:]CORRection:COLLect:CONNection:GENDers <Gender>
Qualifies whether the genders at the test ports (but not their connector types) are equal
or independent.
Suffix:
<Ch>
.
Channel number of the calibrated channel
Parameters:
<Gender> ALL | SINGle
ALL – equal (uniform) genders. If the gender at one port is
changed, the connector type at all other ports is changed
accordingly.
SINGle – independent (possibly non-uniform) genders at the
ports.
*RST: SINGle
Example: See [SENSe<Ch>:]CORRection:COLLect:CONNection:
PORTs
Manual operation: See "Same Connector All Ports / Same Gender All Ports"
on page 467
[SENSe<Ch>:]CORRection:COLLect:CONNection:PORTs <ConnectorType>
Qualifies whether the connector types at the test ports (but not their gender) are equal
or independent. Some calibration types require uniform port connector types.
Suffix:
<Ch>
.
Channel number of the calibrated channel
Parameters:
<ConnectorType> ALL | SINGle
ALL – equal (uniform) connector types. If the connector type at
one port is changed, the connector type at all other ports is
changed accordingly.
SINGle – independent (possibly non-uniform) connector types at
the ports.
*RST: ALL
Example:
CORR:COLL:CONN:PORTS SING
Select independent connector types at the ports.
CORR:COLL:CONN1 N50MALE; CONN4 N75FEMALE;
CONN2?
Select independent connector types at ports 1 and 4. The con-
nector type at port 2 is not changed; the query returns
N50FEMALE.
Manual operation: See "Same Connector All Ports / Same Gender All Ports"
on page 467
