R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1232User Manual 1173.9163.02 ─ 62
[SENSe<Ch>:]CORRection:COLLect:DELete [<CalName>]
Deletes system error correction data generated and stored previously.
Suffix:
<Ch>
.
Channel number of the calibrated channel
Setting parameters:
<CalName> Name of the calibration (string parameter) defined together with
the calibration type ([SENSe<Ch>:]CORRection:COLLect:
METHod:DEFine).
ALL - the analyzer deletes all calibrations.
If nothing is specified the analyzer deletes the last system error
correction stored by means of [SENSe<Ch>:]CORRection:
COLLect:SAVE:SELected[:DUMMy].
*RST: -
Example:
CORR:COLL:METH:DEF 'Test',RSHort,1
Select a one-port normalization at port 1 with a short standard
as calibration type.
CORR:COLL:SEL SHOR,1
Measure a short standard connected to port 1 and store the
measurement results of this standard.
CORR:COLL:SAVE:SEL
CORR:COLL:DEL ALL
Calculate the system error correction data and apply it to the
active channel, then delete the data.
Usage: Setting only
Manual operation: See "Apply" on page 471
[SENSe<Ch>:]CORRection:COLLect:DETector <CalName>[, <CalDetectorType>]
Selects the detector type during manual calibration <CalName>.
Suffix:
<Ch>
.
Channel number
Parameters:
<CalName> Name of a manual calibration previously created e.g. using
[SENSe<Ch>:]CORRection:COLLect:METHod:DEFine
<CalDetectorType> NORMal | AVERage
AVERage
Average detector, recommended for channels measuring traces
using detectors other than the NORMal one
NORMal
Normal (sample) detector, recommended for all other applica-
tions
*RST: NORMal
SCPI command reference
