R&S ZNB Series User Manual

GUI reference
R&S
®
ZNB/ZNBT
473User Manual 1173.9163.02 ─ 62
Add
Adds a new system error correction.
The "Add" button opens the Define Calibration dialog without pre-selected ports.
Delete
Deletes the selected calibration from the list of configured calibrations.
Modify
Edits the selected system error correction: opens the Define Calibration dialog with the
corresponding ports and calibration type pre-selected.
Next
Proceeds to Step 2: Connectors and Cal Kits.
Inactive as long as no calibration is defined.
Define Calibration dialog
you to select the test ports to be calibrated and the calibration type to be used.
Background information
Refer to Chapter 4.5.1, "Calibration types", on page 163 for background information.
Access: Calibration Setting wizard (MultiCal) > Step 1: Ports and Type> "Add" / "Mod-
ify"
Cal softtool
