GUI reference

R&S

ZNB/ZNBT

406User Manual 1173.9163.02 ─ 62

Remote command:

CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute LTARget

CALCulate<Chn>:MARKer<Mk>:REFerence:FUNCtion:EXECute LTARget

CALCulate<Chn>:MARKer<Mk>:FUNCtion:RESult?

CALCulate<Chn>:MARKer<Mk>:REFerence:FUNCtion:RESult?

Search Mode

Displays and sets the current marker search mode.

Select one of the predefined max, min, peak, or target searches or select "Sweep Pro-

gress" to track the position of the sweep cursor.

Remote command:

CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute

CALCulate<Chn>:MARKer<Mk>:REFerence:FUNCtion:EXECute

5.7.6 Bandfilter tab

"Bandfilter" search allows you to search for trace segments with a bandpass or band-

stop shape, and determine characteristic filter parameters.

Background information

Refer to "Bandfilter search" on page 110.

Bandfilter for arbitrary scalar traces

"Bandfilter" search can be used for a broad range of measured quantities (see Chap-

ter 5.2, "Meas softtool", on page 284). To obtain real filter parameters, the trace format

must be "dB Mag", the measured quantity must be a transmission S-parameter and a

frequency sweep must be performed. However, for other formats, measured quantities

or sweep types, the "Bandfilter" functions can still be useful to analyze general trace

properties.

Marker softtool
