R&S ZNB Series User Manual

GUI reference
R&S
®
ZNB/ZNBT
681User Manual 1173.9163.02 ─ 62
5.15 DUT Softtool
For 2nd generation R&S ZNB models (order nos. 1334.3330.xx), the "DUT Centric"
application was moved to a dedicated "DUT" softtool. For a description see Chap-
ter 5.16.3, "DUT Centric application", on page 711.
Access: System – [DUT]
5.16 Applic softtool
The "Applic" softtool gives access to applications and tools that extend the functionality
of the analyzer firmware.
Access: System – [Applic]
Use the combo-box at the top of the softtool to load one of the available applications
and to display the softtool tabs related to this application.
The "External Tools" and "DUT Centric" applications are always available, other appli-
cations are provided by certain software options.
Applic softtool
