GUI reference
R&S
®
ZNB/ZNBT
476User Manual 1173.9163.02 ─ 62
functionality is the same as described for the "SingleCal" version of the wizard (see
"Step 2: Connectors and Cal Kits" on page 465).
Back
Go back to Step 1: Ports and Type.
Start
Start Step 3: Calibration.
Step 3: Calibration
Allows you to acquire error correction data for every required port (pair) and calibration
standard, where "required" depends on the selected ports and calibration types.
Same logic as in the single calibration version of the wizard (see "Step 3: Calibration"
on page 468).
The possibility to "share" measurements between the calibrations and the "Reduced
Through" logic help to keep the number of measurements as small as possible (see
Chapter 4.5.1.11, "Full n-Port calibration with reduced number of Through connec-
tions", on page 173).
5.11.1.7 Power Cal wizard
The "Power Cal" wizard displays a single screen, showing the current source and
receive ports. It allows you to perform "Ref. Receiver", "Meas. Receiver" and scalar
source power ("Source Flatness") calibrations, based on the current power calibration
settings (see Chapter 5.11.3, "Pwr Cal Settings tab", on page 524).
Access: Channel – [Cal] > "Start Cal" > "Power Cal..."
