R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
1267User Manual 1173.9163.02 ─ 62
Suffix:
<Chn>
.
Channel number used to identify the active trace
Usage: Query only
Manual operation: See "Apply" on page 478
[SENSe<Chn>:]CORRection:SSTate?
Returns the system error correction state label of the active trace in channel <Chn>.
The response is a string variable containing the calibration state label in the trace list
('CAL', 'CAI', 'CAL OFF' ..; see Chapter 4.5.4, "Calibration labels", on page 181).
Suffix:
<Chn>
.
Channel number used to identify the active trace
Example: See [SENSe<Ch>:]CORRection:DATE?
Usage: Query only
Manual operation: See "Apply" on page 471
7.3.14.9 [SENSe:]FREQuency...
The [SENSe:]... commands set frequency-related parameters, especially the mea-
surement and display ranges for the different sweep types. The frequency ranges for
the different instrument models are listed below; for more details refer to the data
sheet.
Table 7-17: Frequency ranges of R&S
ZNB/ZNBT analyzers
Frequency settings Start, Stop Center Span
R&S ZNB4 9 kHz to 4.5 GHz >9 kHz to <4.5 GHz 1 Hz to 4.499991 GHz
R&S ZNB8 /
R&S ZNBT8
9 kHz to 8.5 GHz >9 kHz to <8.5 GHz 1 Hz to 8.499991 GHz
R&S ZNB20 /
R&S ZNBT20
100 kHz to 20 GHz >100 kHz to <20 GHz 1 Hz to 19.9999 GHz
R&S ZNB26 /
R&S ZNBT26
100 kHz to 26.5 GHz >100 kHz to <26.5 GHz 1 Hz to 26.4999 GHz
R&S ZNB40 variant 72 10 MHz to 40 GHz >10 MHz to <40 GHz 1 Hz to 39.99 GHz
R&S ZNB40 variants 82,
83 and 84
R&S ZNBT40
100 kHz to 40 GHz >100 kHz to <40 GHz 1 Hz to 39.9999 GHz
R&S ZNB43 100 kHz to 43.5 GHz >100 kHz to <43.5 GHz 1 Hz to 43.4999 GHz
SCPI command reference
