Remote control

R&S

ZNB/ZNBT

826User Manual 1173.9163.02 ─ 62

●

Output buffer:

contains the messages the instrument returns to the controller. It is not part of the

status reporting system but determines the value of the MAV bit in the STB.

All status registers have the same internal structure, see Structure of a SCPI status

For more information on the individual status registers, see Contents of the status reg-

isters.

SRE register

The service request enable register SRE can be used as ENABle part of the STB if the

STB is structured according to SCPI. By analogy, the ESE can be used as the ENABle

part of the ESR.

6.5.1 Overview of status registers

The status registers of the R&S ZNB/ZNBT are implemented as shown below.

Status reporting system
