GUI reference
R&S
®
ZNB/ZNBT
671User Manual 1173.9163.02 ─ 62
If the recall set to be loaded contains a switch matrix configuration and no differences
to the current switch matrix configuration are detected, the recall set is loaded without
further inquiry. Otherwise you are asked if you want to adapt the configuration:
Select "Cancel" to abort the recall process or "OK" to open the Restore Switch Matrix
Configuration dialog that guides you through the required configuration changes.
Note: In case the recall set could only be loaded after adjusting some incompatible
settings, the info message "The setup data changed while loading" is displayed.
Incompatibilities can arise, for example, if you attempt to load a recall set of a different
R&S ZNB/ZNBT model or with different optioning. Not all incompatibilities can be
adjusted.
Remote command:
MMEMory:LOAD:STATe
Save
Saves the active recall set to a file (*.znx|*.znxml).
Displays the Save Dialog that allows you to specify a file name and location for the
recall set file.
Remote command:
MMEMory:STORe:STATe
Recent Files
The buttons are labeled with the last recall sets which were stored in the current or in
previous sessions. They open the corresponding recall set.
5.14.1.2 Restore Switch Matrix Configuration dialog
When opening an existing recall set file, it can be necessary to adapt the current sys-
tem configuration to the switch matrix configuration of the recall set. The "Restore
Switch Matrix Configuration" dialog guides you through this process.
File softtool
