R&S ZNB Series User Manual

GUI reference
R&S
®
ZNB/ZNBT
717User Manual 1173.9163.02 ─ 62
●
one channel for S-parameter measurements
●
one channel for intermodulation measurements
Summary
The "Summary" page of the "DUT Centric Wizard"
●
summarizes the channels to be created and the parameters to be measured
●
allows you where to define these channels (new setup, append to current setup,
replace current setup)
●
allows you to decide whether to proceed with a (suitable) calibration
Calibrate Newly Created Channels
If you finish the "DUT Centric Wizard" with "Calibrate Newly Created Channels"
selected, then, after creating the required (setup and) channels, the FW will proceed
with suitable calibrations.
