R&S ZNB Series User Manual

Command reference
R&S
®
ZNB/ZNBT
893User Manual 1173.9163.02 ─ 62
This simplification is allowed for two-sided DUTs using the same coupon model for the
left and right side (CALCulate:FMODel:DEASsistant:COUPon:LEFT|
RIGHt:TYPE).
Parameters:
<Boolean> ON (1) | OFF (0), where ON means only the left coupon model is
measured (CALCulate:FMODel:DEASsistant:COUPon:
LEFT:MEASure) or loaded from file (CALCulate:FMODel:
DEASsistant:COUPon:LEFT:FILE).
Options: R&S ZNB/ZNBT-K220 | R&S ZNB/ZNBT-K230 | R&S ZNB/
ZNBT-K210
Manual operation: See "Use Same Coupon Left and Right" on page 657
CALCulate:FMODel:DEASsistant:TOOL
<FixtureTool>
Selects the fixture modeling tool to be used in the deembedding assistant.
Parameters:
<FixtureTool> ISD | SFD | EZD
ISD
AtaiTec's In Situ De-Embedding tool
See Chapter 4.7.9, "In-situ de-embedding", on page 251
SFD
PacketMicro's Smart Fixture De-embedding tool
See Chapter 4.7.10, "Smart fixture de-embedding", on page 252
EZD
Eazy Deembedding based on IEEE 370
See Chapter 4.7.8, "Eazy de-embedding based on IEEE 370",
on page 250
Options:
R&S ZNB/ZNBT-K220 | R&S ZNB/ZNBT-K230 | R&S ZNB/
ZNBT-K210
Manual operation: See "Fixture Tool" on page 626
CALCulate:FMODel:DELT...
Commands for Delta-L PCB characterization (see Chapter 4.7.11, "Delta-L 4.0 PCB
characterization", on page 252).
CALCulate:FMODel:DELT:DIRectory................................................................................894
CALCulate:FMODel:DELT:DIRectory:DEFault................................................................... 894
CALCulate:FMODel:DELT:FREQuencies:CURRent?......................................................... 895
CALCulate:FMODel:DELT:FREQuencies:CURRent:COUNt?.............................................. 895
CALCulate:FMODel:DELT:FREQuencies:DEFault?............................................................895
CALCulate:FMODel:DELT:FREQuencies:DEFault:COUNt?................................................ 895
CALCulate:FMODel:DELT:FREQuencies:USEDefault........................................................ 896
CALCulate:FMODel:DELT:FREQuencies:USER?.............................................................. 896
CALCulate:FMODel:DELT:FREQuencies:USER:ADD........................................................ 896
CALCulate:FMODel:DELT:FREQuencies:USER:DELete.................................................... 896
