Command reference
R&S
®
ZNB/ZNBT
951User Manual 1173.9163.02 ─ 62
Example: Suppose that the active recall set contains an active trace no. 1.
CALC:MARK ON
Create marker M1 and assign it to trace no. 1.
CALC:MARK:FUNC:EXEC MAX; RES?
Move the created marker to the absolute maximum of the trace
and query the stimulus and response value of the search result.
Usage: Setting only
Manual operation: See "Max / Min" on page 397
The analyzer provides the following search modes:
Mode Find...
MAXimum Absolute maximum in the search range (see CALCulate<Chn>:MARKer<Mk>:
FUNCtion:DOMain:USER[:RANGe] )
MINimum Absolute maximum in the search range
RPEak Next valid peak to the right of the current marker position
LPEak Next valid peak to the left
NPEak Next highest or lowest value among the valid peaks (next peak)
TARGet Target value (see CALCulate<Chn>:MARKer<Mk>:TARGet)
RTARget Next target value to the right of the current marker position
LTARget Next target value to the left
BFILter
Regular markers
only
Bandfilter search. The results are queried using CALCulate<Chn>:MARKer<Mk>:
BWIDth.
MMAXimum or
MMINimum
Multiple peak search
SPRogress Sweep progress
CALCulate<Chn>:MARKer<Mk>:FUNCtion:RESult?
CALCulate<Chn>:MARKer<Mk>:REFerence:FUNCtion:RESult?
Returns the result (stimulus and response value) of a search started by means of
CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute or CALCulate<Chn>:
MARKer<Mk>:REFerence:FUNCtion:EXECute. The search must be executed
before the command is enabled.
Suffix:
<Chn>
.
Channel number used to identify the active trace
<Mk> Marker number (ignored)
Example: See CALCulate<Chn>:MARKer<Mk>:FUNCtion:EXECute
Usage: Query only
Manual operation: See "Max / Min" on page 397
