Specifications
SM 7-1 D014/D015/D078/D079
Specifications
7. SPECIFICATIONS
7.1 SPECIFICATIONS
7.1.1 MAIN FRAME D014/D015/D078/D079
Copying
Configuration Console
Dimensions (w x d x h)
No ARDF 750 x 850 x 1050 mm (29.5 x 33.5 x 41.3 in.)
With ARDF 750 x 850 x 1230 mm (29.5 x 33.5 x 48.4 in.)
Weight (with ARDF) Less than 298 kg (655.6 lb)
Original Scanning Flatbed with moving 3-line CCD array, image scanning
Copy Process
4-drum dry electrostatic transfer system with internal transfer
belt
ARDF Standard
Development Dry dual-component magnetic brush development
Fusing Oil-less belt fusing system
Engine speed D014/D078 FC 55 cpm, BK 60 cpm
D015/D079 FC 70 cpm BK 75 cpm
Warm-up time EU/AP Less than 75 sec.
NA
D014/D078: Less than 90 sec.
D015/D079: Less than 75 sec.
First copy time FC
D014/D015/D078/D079: Less than 7.5/6.4
sec.
