2.1.4 ELECTRICAL COMPONENT SUMMARY
Heater
No. Name Description
H
Anti-Condensation
Heater
Heat elements that provide heat to keep the paper tray
and paper stack dry.
Motors
No. Name Description
M Air Assist Fan (Front) 1 of 2 fans that cool the tray.
M Air Assist Fan (Rear) 1 of 2 fans that cool the tray.
M Grip Motor
Drives the transport rollers in the feed path that feed
the paper from the tray to the LCT exit motor.
M LCT Exit Motor
Feeds the paper out the LCT and into the entrance of
the copier.
M Lift Motor Raises and lowers the bottom plate of the paper tray.
M Paper Feed Motor
Drives the pick-roller and feed roller that picks up each
sheet and starts to feed it out of the 1st tray.
Board
No. Name Description
PCB Main Board
Controls the operation of all motors and sensors in the
LCT unit.
