Mechanical Layout
SM 13 D350
D350
RT4000
A3/12 x 18
LCT
2.1.2 DRIVE LAYOUT
1. Lift Motor
2. Air Assist Fan Motor
3. Paper Feed Motor
4. Grip Motor
5. LCT Exit Motor
