Finisher Adapter Kit D375
SM 1-99 D014/D015/D078/D079
Installation
Finisher Adapter Kit D375 Installation
The finisher adapter kit must be installed before the finisher and punch unit are
installed.
1. Attach the entrance guide [A] ( x 2).
Attach the entrance guide only if the finisher will be connected directly to the main
machine.
Do not install the entrance guide if you intend to install the Cover Interposer Tray
(B835) or Z-Folding Unit (B660).
2. Remove the finisher rear cover [A] ( x 2).
