DETAILS
B830 52 SM
3.9 SHIFT TRAY OPERATION
3.9.1 OVERVIEW
The movement of the shift tray is controlled by four sensors
,
,
, and
and a
feeler [A] with two actuators [B] and [C].
• The notched actuator [B] is used with sensors
and
.
• The flat actuator [C] is used with sensor
.
• Sensor
is provided with its own actuator [D].
The operation mode determines which parts are used to control the movement of
the shift tray.
Sensor Names
No. Name
Paper Height Sensor – Staple Mode
Paper Height Sensor – Standby Mode
Paper Height Sensor – Z-Fold Full
Paper Height Sensor – Shift/Z-Fold
