Z-Folding Unit ZF4000 (B660)
SM 1-137 D014/D015/D078/D079
Installation
1.17 Z-FOLDING UNIT ZF4000 (B660)
The ZF4000 supports a connection with the D014/D015/D078/D079 copier only when both
of the following conditions are met:
(1) The ZF4000 must be from May 2007 production or later
.
Cut-in S/N:
ZF4000 machine code Cut-in Serial Number
B660-57
K3070400079 May 2007 production
B660-66
8M405700001 May 2007 production
B660-67
K3070500022 May 2007 production
NOTE: For ZF4000 folding units produced from May – December 2007, there is a blue
mark on the outer box and folding unit itself.
(2) The finisher must be an SR5000 (100-Staple) or SR4020 (Saddle Stitch).
NOTE: Connection to a SR4010 finisher is not supported.
1.17.1 ACCESSORY CHECK
Check the quantity and condition of the accessories in the box against the following list:
Description Qty
1. Lock Bracket – Rear (Cover Interposer Tray) 1
2. Lock Bracket – Rear 1
3. Lock Bracket – Front (Cover Interposer Tray)*1 1
4. Lock Bracket – Front 1
5. Ground Plate (Cover Interposer Tray) 1
6. Ground Plate (Z-folding unit) 1
7. Ground Plate (Finisher or Cover Interposer Tray) 1
8. Right Docking Bracket 1
9. Left Docking Bracket 1
10. Power Cord 1
11. Front Spacer 1
12. Rear Spacer 1
⇒
Rev. 02/2008
